Modular Stop board segments are fabricated in 100mm increments and connected to isolate flows for maintenance, re-direction or containment.
Features
- Primarily designed for flow isolation, AWMA Stopboards also regulate flows via overshot level control
- Designed to suit square and rectangular openings up to 6m wide
- Up to 30% lighter than traditional designs
- Reduces OH&S risks – Single segments are less than 20kg for manual lift
- Stopboard segments up to 3m in depth are suitable for mechanical lifting
- Dedicated extruded section with embedded seals
- Uni-directional as standard, bi-directional sealing designs available upon request
- Tapered entry point on centre location facilitating easy install and removal of stop boards
- Variety of AWMA Lifting Mechanisms and Storage Solutions available
For water control structures of modular segments to suit custom sizes see AWMA Stop Logs, or for singular structures see AWMA Bulkhead Gates.
Contact AWMA today to discuss sluice gate mechanisms for your organisation or explore a range of other penstocks and water management systems that we offer.
Projects utilising AWMA’s Segmented Stopboards:
